SE-650

Reference:

$1,350.00

4 Input HD digital video switcher

The SE-650 is Datavideo's most affordable SDI+HDMI switcher available. With 2 SDI inputs and 2 HDMI inputs, the SE-650 is compatible with both professional and consumer-grade cameras while being one of the least expensive switchers in our catalog.



The SE-650's intuitive control panel makes switching a piece-of-cake for experienced users, as well as for beginners such as volunteers and students. Though it's geared for novice users, the SE-650 is packed with advanced features such as lumakey and chromakey. Down stream keyers (DSK) , up stream keyers (USK) and picture-in-picture(PIP) generators combined with a dual chromakeyer give you enough freedom to be creative.



The SE-650's built-in audio mixer means that you've got everything you need to control your audio input levels. For most productions, this means that there's no need to buy a separate external audio mixer. Choose between a variety of pre-saved animated stinger transitions and virtual set backgrounds. You can save a complex process into a user memory, turning multiple tasks into a one-finger job.

Package Weight 3.00 kg
Quantity
In Stock



Secured Payment



Delivery Policy



Refunds & Return Policy



Video Standard

HD



Video Format

1080i 50/59.94/60Hz

720p 50/59.94/60Hz



Video Processing

SDI: 4:2:2

HDMI: YUV 4:2:2 10 bit, RGB: 4:4:4



Input Routable / Crosspoint

All 4, repeatable



Video Input

2x HD-SDI

2x HDMI



Computer Graphic Interface

2 via HDMI



Video Output

2 x HDMI (1 is MV, 1 is Assignable)

1 x HD-SDI (Assignable)



Built-in Multi-view Monitoring Out

HDMI & SDI assignable



Analogue Audio Input

1 x Stereo RCA (L/R)

2 x Mono Microphone



Analogue Audio Output

1 x Stereo RCA (L/R)

1 x Stereo headphone (Mini Jack with volume control)



Digital Embedded Audio Support

Input 2 channels, Output 2 channels



A+V Switching

Yes



Chromakey

2



USK

2x Keyer support Chromakey/ Linear/ Luma Key



DSK

1x DSK support Lumakey/ Linear key (Key / Fill)



Picture in Picture

1



Logo Insertion

1



Still Store

500



Effects

FTB, Cut, 32 Wipe with border



Transition Preview

Full transitions preview



Sync / Reference In/Out

Built-in Genlock (internal)



Tally Output

1x D-sub 15pin, dual color



PC Remote Control

DVIP (Ethernet)



Built-in Audio Mixer

Yes, 4 channels



Special Features

Free Virtual Set and Stinger transition included



Chassis

Unibody



Dimension (LxWxH)

400 x 250 x 82 mm



Weight

1.9 kg



Power

DC 12V, 29W



Operating Temp. Range

0~40 °C



Options

CB-46/47/60/61/62



What's in the Box

1 x SE-650 product

1 x AD Switch DC 12V with AC Cord

1 x Thank You Card
